460 Yield Steel Plate
Designers are increasingly using 460 MPa yield plate to combine increased strength with savings in Weight.
With availability in both structural and pressure vessel grades in a wide range of plate sizes and thicknesses Brown McFarlane provides your stock answer.
We recognise the need for an ex-stock source of 460 yield plate and are able to offer the following material:
-
EN 10028-3 P460NL1/2
-
EN 10028-3 P460NH
-
EN 10025-3 S460N
Applications
- Bridges
- Grouted tees/Grouted sleeves
- Pipe caps/Pipe fittings
- Pipe lines
- Plate girders
- Pressure vessels
- Road tankers
Technical Specifications
Chemical Composition (Ladle %)
C
max |
Si
max |
Mn
max |
P
max |
S
max |
Al total
min |
N
max |
| 0.20 |
0.60 |
1.10 to 1.70 |
0.020 |
0.005 |
0.020 |
0.025 |
Chemical Composition (Ladle %)
Cr
max |
Cu
max |
Mo
max |
Nb
max |
Ni
max |
Ti
max |
V
max |
| 0.30 |
0.70 |
0.10 |
0.05 |
0.80 |
0.03 |
0.20 |
| Nb + Ti + V |
Carbon Equivalent |
| 0.22% Max |
Up to 30mm thick 0.50% max |
|
Over 30mm thick 0.53% max |
Mechanical Properties
| Product Thickness |
Yield Strength
MPa (min) |
Tensile Strength
MPa |
Elongation % (min) |
| < 16mm |
450 |
570 to 730 |
17 |
| 16 to 50mm |
450 |
570 to 720 |
17 |
| > 50mm |
430 |
570 to 720 |
17 |
Minimum Impact Values Transverse Direction
| Grade |
-50 |
-40 |
-20 |
| P460NH |
-- |
-- |
30J |
| P460NL1 |
-- |
27J |
35J |
| P460NL2 |
27J |
30J |
40J |
Applicable for plate thickness less than 250mm
Size range
EN 10028 P460 NL1 / NL2 / NH - EN10025-3 S460 N / NL1
| Thickness: 6/8/8.3/10/12/16/20/25/30/35/40/45mm |
Length: 12000 |
Width:3000 |
| Thickness: 50/55/60mm |
Length: 12000 |
Width:3000 |
Brochure Download
Manufactured by leading European mills, featuring a low CEV and a complete range of plate sizes & thicknesses.
Download (730KB)
