Perfiladeira aço frio de alto rendimento | Brown McFarlane

About High Yield Cold Forming Steel Plate from Brown McFarlane

Brown McFarlane carries a stock of high yield strength steel plate manufactured for applications where cold forming of the metal is required. The steel offers guaranteed mechanical properties, excellent cold formability, and a clean surface finish.
• In-house high definition plasma profiling guarantees tight tolerances with minimum distortion.
• High yield cold forming steel plate offers both strength and formability, with excellent surface quality, dimensional and geometrical accuracy and uniformity of properties.
• Steel structures can be made lighter with cold-formed steel which means that the payload of machines and equipment can be increased and fuel consumption reduced.

More information

Welding High Yield Cold Forming Steel Plate
Despite its high strength, this steel is easier to weld than conventional lower yield grades. Good weldability means that preheating is not necessary under normal conditions.

Surfaces must be both dry and clean before welding and welding materials must be of sufficiently low hydrogen content.

You can find specifications of our high yield steel grades for cold forming in the table below

Applications

  • Agricultural equipment
  • Axle parts
  • Crane booms
  • Defence applications
  • Mechanical handling
  • Side impact protection systems
  • Truck bodies
  • Vehicle chassis

Chemical properties

Steel grade C mac Si max Mn max P max S Max Al max
S700MC 0.10 0.20 2.10 0.02 0.01 0.015

Mechanical properties

Steel grade Yield (min) MPA Tensile MPA Elongation (min) A5% Impact strength (min) Longitudinal CEV %
t degrees C Charpy V (J) CEV average CEV maximum
S700MC 700 750 – 930 15 -20 40 0.37% 0.41%

Size range

Thicknesses Widths Lengths
3, 5, 5, 6, 8, 10, 12mm 1250mm & 1500mm Up to 14m
